Glass fiber industrial cloth

Category： Glass fiber industrial fabric
INQUIRY EMAIL

Product Introduction：

Glass fiber industrial fabric mainly includes glass fiber plain weave fabric, glass fiber twill fabric, and glass fiber satin fabric. Plain weave fabric, twill fabric, and satin fabric, due to their unique chemical and physical properties, can be combined with other materials to derive various related materials with a wide range of applications. They are excellent insulation materials and ideal substitutes for asbestos fabric. They have characteristics such as high tensile strength in both vertical and horizontal directions, breathability, water resistance, and good sealing performance, and are mainly used for the preparation of fire prevention, insulation, and sound insulation materials.

Plain weave structure: It has a compact structure, a flat structure, and clear patterns, suitable for most industrial applications such as electrical insulation materials and reinforcement materials. Represented by CW140, CW260, and imitation 7628 #.

Twill weave: Compared with plain weave fabrics, using the same warp and weft yarns can form fabrics with high density, high strength, and a more soft and loose structure. It is suitable for use as a base fabric for ordinary reinforcement materials, fire blankets, air dust filtration materials, and coating products. Represented by 3731 # and 3732 #.

Satin weave: Compared with plain weave and twill weave, using the same warp and weft yarn can weave fabrics with higher density, mass per unit area, strength, and looseness. It has a good hand feel and is suitable for reinforcing materials with high mechanical performance requirements. Represented by 3784 # and 3788 #.

Product specifications:

Specification and model	Organizational fabric	Fabric width (cm)	Warp and weft density (cm)	gram weight (g/m2)	thickness (mm)	coil length (m)
3732	twill	90-200	2010/1812	430	0.40	50-400
3731	twill	90-200	14*10	340	0.35	50-400
3784	satin weave	100-200	18*10	840	0.80	50-200
Imitation 7628	lain weave	105-127	17*13	210	0.18	50-200
CW260	lain weave	100-200	12*8	260	0.24	50-400
CW200	lain weave	100-200	9*8	200	0.20	50-600
CW140	lain weave	100-200	12*9	140	0.12	50-800
CW100	lain weave	100-200	8*8	100	0.10	50-100

Ganzhou Wolfe Trading Co. , Ltd. is a large Chinese manufacturer and exporter of fiberglass and its products, our main products are fiberglass yarn, fiberglass mesh cloth, fiberglass industrial cloth, fiberglass self-adhesive tape, fiberglass fire blanket, fiberglass-covered aluminum foil self-adhesive cloth, etc. , welcome Chinese and foreign customers to negotiate procurement.
